Wind turbine bolt heat treatment line
Features:
● Product Name:Wind turbine bolt heat treatment line
● Wind turbine bolt diameter: 36-120mm
● Process: Quenching & tempering
Product Detail
Application Video
Product Tags
Wind turbine bolts require very high tensile strength, high yield strength and good low temperature impact toughness. 42Crmoa steel is a kind of medium carbon high strength alloy structural steel, which can meet the above requirements under the condition of quenching and tempering. For wind turbine bolts with diameter greater than 36mm and 10.9 grade, Forever wind turbine bolt heat treatment line can finish the heat treatment process well.
● Product Name:Wind turbine bolt heat treatment line
● Wind turbine bolt diameter: 36-120mm
Configuration for Wind turbine bolt heat treatment line
|
No. |
Specification |
Quantity |
|
1 |
MF induction heating power supply |
2 sets |
|
2 |
Capacitor Cabinet |
2 sets |
|
3 |
GTR Ø30xL Inductor(3 segments) |
1 set |
|
|
GTR Ø60xL Inductor(3 segments) |
1 set |
|
4 |
Roller Table(four) |
1 set |
|
5 |
Storage rack,the length is 6 meters |
1 set |
|
6 |
Feeding rack including transmission roller,the distance is 500mm between two rollers,the length is 6 meters |
1 set |
|
7 |
Infrared thermometer |
2 sets |
|
8 |
Remote console |
1 set |
|
9 |
Product qualification certificate and maintenance instruction |
|
Induction heater Parameter Design
According to the different parameters of the wind turbine bolt,our engineer will optimizatized design different inductor group to get the effect of high efficiency. The inductor for tempering will increase the inductor quantity and adding tempering holding box to get better structure after tempering, ensuring the wind turbine bolt performance meets the requirements.
| Bar Diameter | Bar Length | Heating Temp. | Production capacity |
| Φ36-45mm | 1500mm | 1125°C ± 25 | 3T/H |
| Ø60mm | 6000mm | 1200℃ | 4.4T/H |
| Ø70mm | 6000mm | 1200℃ | 5.3T/H |
| Ø80mm | 6000mm | 1200℃ | 6T/H |
| Billet size | Billet length | Heating Temp. | Production capacity |
| 60*60mm2 | 3m-4 m | 1000℃-1100℃ | 25T/H |
| 75*75mm2 | 3-6 m | Room Temp.-1100℃ | 25T/H |
| 100*100mm2 | 2 m | 750℃-1000℃ | 7T/H |
| 120*120mm2 | 750℃-1100℃ | 30T/H | |
| 120*120mm2 | 11.5-12.5m | 950℃-1150℃ | 90T/H |
| 125*125mm2 | 6 m | Room Temp.-1200℃ | 8T/H |
| 125*125mm2 | 2 m | 750℃-1000℃ | 7T/H |
| 130*130mm2 | 6 m | 950℃-1150℃ | 50T/H |
| 135*135mm2 | 6 m | 950℃-1150℃ | 100T/H |
| 150*150mm2 | 11.5-12.5m | 950℃-1150℃ | 70T/H |
