Induction heating equipment for continuous casting billets

Forever specializes in providing continuous casting billet heating furnace . In the development process, Forever Electromechanical has formed a unique competitive advantage in the brand of induction heating equipment for continuous casting billets: leading independent research and development capabilities, leading the way

Advanced production technology, excellent after-sales service, high-end talent team, and scientific management structure have formed a market reputation for excellent quality and excellent service of induction heating equipment for continuous casting billets.

www.hy-inductionheater.com

Advantages and characteristics of continuous cast billet heating machine :

1. The control system of induction heating equipment for continuous casting billets: The entire heating process is automatically controlled by PLC, and production records such as heating quantity are displayed in a timely manner. This console is used alone, with a specially customized human-machine interface, highly user-friendly operation instructions, fully digital, high depth adjustable parameters, and a one click restore function, making it easy to operate.

2. steel billet continuous casting and rolling heating furnace feeding and guiding system: Each axis is driven by an independent motor reducer, with multiple axis drives set up and controlled by a single frequency converter to ensure synchronous operation of multiple axes. High quality components are selected, with reliable quality and stable operation. Using 304 non-magnetic stainless steel guide wheels to maintain moderate elasticity in the axial direction, in order to adapt to the allowable bending range of the steel billet.

3. The closed-loop temperature control of the continuous casting billet heating equipment is composed of an American Raytheon infrared thermometer and a German Siemens S7 closed-loop control system. The power supply is automatically adjusted according to the initial temperature and feed rate of the steel billet entering the induction heater, so that the heating temperature remains constant before being discharged from the furnace and the workpiece is heated uniformly.

4. Separate design of capacitor cabinet and furnace body cabinet for continuous casting billet induction heating equipment (capacitor cabinet position according to user requirements)

5. All cabinets are sandblasted, sprayed with plastic, and painted. The waterways are made of thick walled stainless steel. The heating equipment for continuous casting and rolling of steel billets is corrosion-resistant and has a long service life. The equipment is equipped with a large LCD temperature display screen (convenient for on-site personnel to observe and display data).

6. Power supply system for steel billet induction heating equipment: Double rectifier 12 pulse or 24 pulse KGPS1000-1000KW single power supply for independent use or multiple power supplies for parallel use. Install dedicated transformers on the equipment to reduce the impact of harmonics on the power grid. Users can use it with confidence, safe and reliable.
