Medium Frequency Induction Heating Equipment

Medium Frequency Induction Heating Equipment

Features:

Application: Forging , Rolling & Quenching

Material: Carbon steel, Brass,Iron,Alloy steel,Stainless steel,Aluminum

Diameter Allow: Φ20-300mm

Length Allow:Not limited

Product Detail

Application Video

Product Tags

Medium Frequency Induction Heating Equipment

Medium Frequency Induction Heating Equipment Suppliers-Forever is dedicated to the world of induction heating.-Induction heating, heat treatment & forge heating.

Induction heating is efficient, easily controlled, uses no energy when not heating, and puts the heat where you want it, when you want it. No idle time, no massive refractories to heat, and close coupling enables you to use energy in the best possible way.

http://www.hy-inductionheater.com/case/induction-heat-treating-equipment-for-sale.html

Customer can get the advantages & flexibility in one company

A single point of contact gives customers global expertise on a variety of thermal processing applications,including:

● Hardening, tempering and annealing

● Billet and bar forging and warm forming

● Stress relieving and pre-heating

● Strip and slab heating

● Copper tube annealing

http://www.hy-inductionheater.com/products/aluminum-billet-induction-heater.html

Forever Medium Frequency Induction Heating Equipment advantages

● Heating fast and uniform.

● Power saving 10% or above:Less harmonics, high power factor, load output voltage is high, the load coil current is low,small power consumption.

● 100% successful starting.Reliable frequent starting is available.

● Easy installation & commission and simple operation.

● Safe and reliable.Perfect protections for long life performance and very safe for operators. Automatic protections for water temperature,water pressure,phase shortage,overcurrent and undervoltage.

● High reliability:Adopt famous brand components which reduce fault rate and make sure the equipment can run reliably.

    cases

    Bar Diameter Bar Length Heating Temp. Production capacity
    Φ36-45mm 1500mm 1125°C ± 25 3T/H
    Ø60mm 6000mm 1200℃ 4.4T/H
    Ø70mm 6000mm 1200℃ 5.3T/H
    Ø80mm 6000mm 1200℃ 6T/H
    Billet size Billet length Heating Temp. Production capacity
    60*60mm2 3m-4 m 1000℃-1100℃ 25T/H
    75*75mm2 3-6 m Room Temp.-1100℃ 25T/H
    100*100mm2 2 m 750℃-1000℃ 7T/H
    120*120mm2   750℃-1100℃ 30T/H
    120*120mm2 11.5-12.5m 950℃-1150℃ 90T/H
    125*125mm2 6  m Room Temp.-1200℃ 8T/H
    125*125mm2 2 m 750℃-1000℃ 7T/H
    130*130mm2 6 m 950℃-1150℃ 50T/H
    135*135mm2 6 m 950℃-1150℃ 100T/H
    150*150mm2 11.5-12.5m 950℃-1150℃ 70T/H

    As our induction heating furnace  is all customized, the above parameters are only for your reference.
